HardDrive Synthetic Media Filter - Black - PS171B-SM

Media enhancement by M-Pleating, increases Dust Holding Capacity (D.H.C) and reduces pressure drop
The zigzag pleating pattern provides more filtration area allowing more dust holding capacity (DHC)
Additional filtration area gives the oil more room to flow, resulting in lower pressure drop
The media is resin-impregnated to ensure structural integrity during its operation under pressure and temperature spikes Forming tapped thread for easy installation and spin-on
Pre-lubricated gasket
The gasket is lubed from the factory to aid installation
The base plate is covered with shrink film to ensure that the lube stays there until the time of usage and dust protection
Standard features plus the following:
Heat-resistant Anti-Drainback valve (ADBV)
Unlike standard nitrile rubber, silicone rubber has a higher heat-resistance
The enhanced ADBV will prevent dry starts and provides durability throughout the extended life of the filter
17mm Hex Nut
Easy for service and removal after prolonged usage
The nut is designed for safety wire attachment if needed
16 Weld spots for higher nut fatigue strength
+30% Gauge thickness for higher burst strength
Oval inlet hole for even lower flow resistance
