Width: 811mm
Height: 92mm
Rise: 52mm
Base: 117mm
Sweep: 52mm
Control Length: 222mm
Features a tapered outer wall resulting in a 1-1/8in. clamping diameter and 7/8in. diameter at the control ends
7010 T6 aluminum with a braceless design and 5.0mm wall thickness at the bends to add strength
Laser etched positioning grid
Knurled grip area increases bonding between bars and grips
Shot peened, anodized finish protects against corrosion
Requires1-1/8in. bar mounts
Specifications| Material | 7010-T6 Aluminum |
|---|
| Clamping Diameter | 1-1/8" |
|---|
| Rise | 2-1/16" |
|---|
| Features | Smooth, Unknurled / Includes Pad |
|---|
| Pullback/Sweep | 2-1/16" |
|---|
| Base Color | Black |
|---|
| Controls Diameter | 7/8" |
|---|
| Type/Bend | OEM Replacement Bend / Fatbar |
|---|
| Clamping Width | 4-5/8" |
|---|
| Color/Finish | Black / Anodized |
|---|
| Finish | Anodized |
|---|
| Height | 3-5/8" |
|---|
| Product Name | Handlebar |
|---|
| Style | Universal |
|---|
| Handlebar Diameter | 1-1/8" |
|---|
| Width | 32" |
|---|
