Width: 819mm
Height: 100mm
Rise: 58mm
Base: 80mm
Sweep: 47mm
Control Length: 211mm
Features a tapered outer wall resulting in a 1-1/8in. clamping diameter and 7/8in. diameter at the control ends
7010 T6 aluminum with a braceless design and 5.0mm wall thickness at the bends to add strength
Laser etched positioning grid
Knurled grip area increases bonding between bars and grips
Shot peened, anodized finish protects against corrosion
Requires1-1/8in. bar mounts
Specifications| Clamping Diameter | 1-1/8" |
|---|
| Color/Finish | Orange / Anodized |
|---|
| Height | 4" |
|---|
| Base Color | Orange |
|---|
| Width | 32-1/4" |
|---|
| Rise | 2-11/16" |
|---|
| Features | Includes Pad / Smooth, Unknurled |
|---|
| Handlebar Diameter | 1-1/8" |
|---|
| Product Name | Handlebar |
|---|
| Type/Bend | Trials 100 / Fatbar |
|---|
| Clamping Width | 3-1/8" |
|---|
| Controls Diameter | 7/8" |
|---|
| Material | 7010-T6 Aluminum |
|---|
| Finish | Anodized |
|---|
| Pullback/Sweep | 1-7/8" |
|---|
| Style | Universal |
|---|
