Width: 805mm
Height: 97mm
Rise: 64mm
Base: 115mm
Sweep: 65mm
Control Length: 200mm
Features a tapered outer wall resulting in a 1-1/8in. clamping diameter and 7/8in. diameter at the control ends
7010 T6 aluminum with a braceless design and 5.0mm wall thickness at the bends to add strength
Laser etched positioning grid
Knurled grip area increases bonding between bars and grips
Shot peened, anodized finish protects against corrosion
Requires1-1/8in. bar mounts
Specifications| Color/Finish | Anodized / Blue |
|---|
| Pullback/Sweep | 2-9/16" |
|---|
| Type/Bend | Fatbar / High / CR |
|---|
| Handlebar Diameter | 1-1/8" |
|---|
| Product Name | Handlebar |
|---|
| Width | 31-3/4" |
|---|
| Base Color | Blue |
|---|
| Clamping Width | 4-1/2" |
|---|
| Features | Includes Pad / Smooth, Unknurled |
|---|
| Height | 3-13/16" |
|---|
| Style | Universal |
|---|
| Clamping Diameter | 1-1/8" |
|---|
| Controls Diameter | 7/8" |
|---|
| Material | 7010-T6 Aluminum |
|---|
| Finish | Anodized |
|---|
| Rise | 2-1/2" |
|---|
