Designed with a combination of shorter durations and higher lifts to offer the advantages of a broad torque output through the entire rpm range
Designed for hydraulics, but could be run with solids
Specifications| Intake Duration | 232° |
|---|
| Intake Lift at TDC | 0.136" |
|---|
| Application | Intake / Exhaust |
|---|
| Exhaust Lobe Centerline | 100° |
|---|
| Intake Lobe Centerline | 100° |
|---|
| Exhaust Lift | Shovel: 0.427" Pan: 0.450" |
|---|
| Exhaust Open | 36° |
|---|
| Intake Lift | Shovel: 0.427" Pan: 0.450" |
|---|
| Exhaust Duration | 232° |
|---|
| Exhaust Lift at TDC | 0.136" |
|---|
| Grind | #1 |
|---|
| Intake Close | 36° |
|---|
| Exhaust Close | 16° |
|---|
| Model | Low Compression |
|---|
| Product Name | Cam |
|---|
| Color/Finish | Gray |
|---|
| Intake Open | 16° |
|---|
