Manufactured from 1in. OD x .120in. wall seamless 4130 chromoly tubing
All bends are created with internal mandrels on a CNC bender to reduce flat spots in the bends
All welded joints are precision-mitered and TIG-welded
Available in chrome or black electroplated finishes and either smooth for aftermarket hand controls/custom applications or slotted for stock OEM switches and levers
All T-Bar style bars have 3-1/2in. on-center mounting points
NOTE: Not notched for TBW applications.
Specifications| Finish | Chrome |
|---|
| Controls Diameter | 1" |
|---|
| Features | Smooth, Unknurled / Slotted |
|---|
| Material | Chromoly |
|---|
| Clamping Diameter | 1-1/8" |
|---|
| Pullback/Sweep | 2-3/4" |
|---|
| Rise | 4-1/2" |
|---|
| Base Color | Silver |
|---|
| Product Name | Handlebar |
|---|
| Center Width | 5" |
|---|
| Style | Universal |
|---|
| End Rise | 4" |
|---|
| Type/Bend | High / Tracker |
|---|
| Color/Finish | Chrome |
|---|
| Handlebar Diameter | 1-1/8" |
|---|
| Height | 4-1/2" |
|---|
| Width | 30" |
|---|
